Ultrasound Case of the Month: August 2018

The Case

This is an 82 year-old male who presented to the ED with acute chest pain and palpitations. He had a known history of AAA s/p repair. Patient denied abdominal, back, or flank pain. There was no loss of consciousness. An EKG was performed and was consistent with SVT with aberrancy. A bedside abdominal ultrasound was performed and the following images were obtained:

 Figure 1: Proximal axial abdominal aortic ultrasound

Figure 1: Proximal axial abdominal aortic ultrasound

 Figure 2: Longitudinal abdominal aorta ultrasound

Figure 2: Longitudinal abdominal aorta ultrasound

 Figure 3: Distal axial abdominal aorta ultrasound

Figure 3: Distal axial abdominal aorta ultrasound

Diagnosis

Known AAA s/p repair (also SVT with aberrancy)

Case Follow-up

The patient remained HDS and adenosine was given with good effect. He was admitted to medicine, and had no further episodes of SVT. He was discharged home with cardiology follow up.

Discussion

The images were acquired using the curvilinear probe. The probe was placed on the abdomen just superior of the umbilicus and just left of midline. Both longitudinal and axial views were acquired.

Ultrasound is the initial test of choice for suspected AAA in the ED. It has sensitivity of 94-99%, and has been shown to decrease mortality in AAA patients by 20-50% compared to CT--likely due to decreased time to diagnosis.

A normal abdominal aorta is typically < 3cm in diameter. A complete AAA ultrasound should evaluate the aorta from the xiphoid process past the aortic bifurcation. US may be considered positive if the aorta is >3 cm in a patient with clinical concern for AAA,  or > 5 cm without clinical concern.

Faculty Reviewer: Dr. Kristin Dwyer

For an in-depth tutorial on the abdominal aorta ultrasound, check out this video from EM:RAP HD:

Additional Resources

https://cdemcurriculum.com/bedside-ultrasound-aaa-examination/

https://radiopaedia.org/articles/abdominal-aortic-aneurysm

https://www.acep.org/sonoguide/abdominal_aortic_aneurysm.html

http://5minsono.com/aaa/

Getting a Hand-le on Pyogenic Flexor Tenosynovitis

CASE

A 45-year-old, right-hand dominant, diabetic female presents with one day of right index finger swelling and pain. She is two weeks status-post right index and middle finger trigger release. In the ED, she is febrile to 101 degrees Fahrenheit, and her exam is notable for fusiform swelling of the digit which is held in flexion. She has pain with passive ROM and tenderness along the flexor tendon.

 Figure 1. Erythematous, diffusely swollen index finger. Courtesy of  Orthobullets

Figure 1. Erythematous, diffusely swollen index finger. Courtesy of Orthobullets

 Figure 2. Plain radiograph of the hand.

Figure 2. Plain radiograph of the hand.

QUESTION
What is the most sensitive and specific finding to diagnose pyogenic flexor tenosynovitis?

A.      Finger held in flexion.

B.       Pain along the flexor tendon sheath.

C.       Fusiform swelling of the digit.

D.      Pain with passive extension.

Trick question! It's actually none of the above. Read on to find out why.

REVIEW

Flexor tenosynovitis consists of inflammation of the flexor tendon and its synovial sheath. The synovial sheath is comprised of both a visceral layer that adheres to the tendon and an outer parietal layer. Inflammation can lead to accumulation of fluid in this potential space and, when infection is the inciting etiology, the condition is called pyogenic flexor tenosynovitis (PFT).

PFT is a surgical emergency – it can lead to substantial morbidity, such as loss of function, tendon necrosis or rupture, deep space infection, and amputation. The prevalence of PFT is estimated at 2.5 - 9.4% of all hand infections (1, 2).

ANATOMY

 Figure 3. Flexor tendon sheaths of the hand.    Courtesy of  Orthobullets

Figure 3. Flexor tendon sheaths of the hand.
Courtesy of Orthobullets

There are many anatomic variations to the flexor tendon sheath anatomy, but common themes exist.

  • In the fingers, the distal sheaths terminate at the insertion of the FDP (near the DIP joint).
  • In the thumb, the sheath terminates at the insertion of the FPL (near the IP joint).
  • For digits 2-4, the sheaths commonly extend just proximal to the A1 pulley (near the MCP joint).
  • The small finger and thumb sheaths typically communicate with the ulnar and radial bursae, respectively. As a result, infection can spread from the little finger to the thumb, or vice versa, leading to the development of a horseshoe abscess.

PATHOGENESIS

PFT can be caused by three mechanisms:

  •  Direct inoculation (most common)
    • Trauma (associated with skin flora):
      • Staphylococcus aureus is the most common organism
      • IVDU (MRSA)
      • Fresh/salt water (Mycobacterium marinum)
      • Plants (Sporotrichosis)
    • Bite wounds (polymicrobial)
      • Cat/dog (Pasteurella)
      • Human (Eikenella)
  • Contiguous spread from nearby soft tissue structures
    • Examples: felon, septic joint, deep space infection
  • Hematogenous spread
    • Neisseria gonorrhea – consider in sexually active patient with polyarthralgias and/or skin lesions
    • Mycobacteria – rubbery masses over the tendon sheath

RISK FACTORS

In a study of 75 patients with PFT, Pang et al. identified the following risk factors that correlated with worsening clinical outcomes, especially amputation rate and effect on total active motion (3):

  • Age >43
  • Presence of DM, PVD, or renal failure
  • Polymicrobial infection
  • Subcutaneous purulence
  • Digital Ischemia

Other notable risk factors are immunocompromised and intravenous drug use.

DIFFERENTIAL DIAGNOSIS

In addition to PFT, the differential diagnosis for a red, swollen digit(s) or hand includes felon, herpetic whitlow, cellulitis, abscess, septic arthritis, gout, and pseudogout.

KANAVEL’S SIGNS

Kanavel notably indentified four criteria for diagnosing PFT (4):

  • Finger held in passive flexion
  • Pain with passive extension
  • Tenderness along flexor tendon sheath
  • Fusiform swelling or “sausage digit”

Although Kanavel’s signs are the hallmark for clinical detection of PFT, no studies have validated their sensitivity and specificity, and there is no consensus among studies regarding which sign is most predictive of PFT (5, 6). It is important to remember that a negative exam does not rule out PFT, so if we cannot rely solely on Kanavel’s signs, what other tools can be used in the ED to assist in early recognition of PFT?

ULTRASOUND

Point-of-care ultrasound is a quick and non-invasive way to help distinguish PFT from other conditions such as cellulitis or abscess, and ultrasound can guide appropriate management (7-9). Ultrasound appears to be sensitive study for detecting PFT (10, 11) and may actually be more sensitive than clinical exam in detecting tenosynovitis (12, 13). Although radiographs are typically ordered to evaluate for bony abnormalities or foreign body, ultrasound has the added benefit of detecting radiolucent foreign bodies.

 Figure 4 .  Water bath technique for ultrasound of the hand.

Figure 4. Water bath technique for ultrasound of the hand.

The water bath technique is a simple and effective way to image structures of the hand:

Step 1: Fill a large basin with warm water.

Step 2: Have the patient submerge their hand in the bath.

Step 3: Float the linear transducer in the water above their hand and direct as needed.

Since the water bath acts as an acoustic medium, the probe does not need to be in direct contact with the hand—and your patients will be grateful if they have any tenderness.

 Figure 5.   Normal flexor tendon anatomy on ultrasound.

Figure 5. Normal flexor tendon anatomy on ultrasound.

Anechoic or hypoechoic fluid within the tendon sheath and thickening of tendons are highly suspicious for pyogenic flexor tenosynovitis in the appropriate clinical context. Compare this with the cobblestone appearance of cellulitis on ultrasound.

 Figure 6. Cellulitis. Note the cobblestone appearance caused by subcutaneous edema.

Figure 6. Cellulitis. Note the cobblestone appearance caused by subcutaneous edema.

 Figure 7. Example of anisotropy. Note the change in the flexor tendon from a hyperechoic signal (star) to a hypoechoic signal (arrow).

Figure 7. Example of anisotropy. Note the change in the flexor tendon from a hyperechoic signal (star) to a hypoechoic signal (arrow).

Scan in two planes, and compare to the contralateral side if needed. Because of anisotropy, be sure to hold the probe perpendicular to the tendon in order to avoid mistaking tendon for fluid.

False negatives can occur with ultrasound in early PFT when fluid accumulation is minimal, so clinical suspicion based on all information gathered should guide clinical management.

TREATMENT

Once PFT is suspected, it is important to initiate empiric antibiotic therapy—commonly vancomycin and/or piperacillin/tazobactam—to improve clinical outcomes (14). Elevate the hand to reduce swelling. Definitive treatment, however, is surgical incision and drainage, so early consultation of a hand specialist is also necessary. Cultures can be obtained in the OR and antibiotic therapy narrowed once speciation and sensitivities are determined.

Although success with non-surgical treatment has been described, no studies have evaluated outcomes for PFT with antibiotics alone, and further investigation is warranted (14).

CASE OUTCOME

The patient was started on vancomycin, and orthopedics was consulted. She was taken to the OR for an emergent incision and drainage that was notable for the release of frank pus from the index finger flexor sheath as well as murky fluid in the palm. Piperacillin/tazobactam was added, and the patient showed gradual improvement in erythema, swelling, and range of motion throughout her hospital course. Speciation and sensitivities revealed methicillin-sensitive Staphylococcus aureus (MSSA), and antibiotics were narrowed. The patient was transitioned to oral antibiotics and discharged on post-operative day #4 with orthopedic follow-up.

TAKE HOME POINTS

  • Pyogenic flexor tenosynovitis can result in significant morbidity and is a surgical emergency.
  • Kanavel’s signs are used to diagnose PFT, but remember that the absence of Kanavel’s signs does not exclude early PFT:
    • Fusiform swelling.
    • Finger held in flexion.
    • Pain with passive extension.
    • Tenderness along the flexor tendon sheath.
  • Point-of-care ultrasound is a helpful tool in distinguishing PFT from other causes such as cellulitis or abscess.
  • Consider using the water-bath technique to image the hand.
  • Look for hypoechoic or anechoic fluid within the tendon sheath or thickened tendons.
  • If PFT is suspected, start broad-spectrum empiric antibiotics, splint and elevate the hand, and consult a hand specialist for possible operative management.

Faculty Reviewer: Dr. Jeff Feden

REFERENCES:

(1) Weinzweig N, Gonzalez M. Surgical infections of the hand and upper extremity: a county hospital experience. Ann Plast Surg. 2002; 49(6):621-7.

(2) Glass KD. Factors related to the resolution of treated hand infections. J Hand Surg. 1982;7(4):388-94.

(3) Pang H-N, Teoh L-C, Yam AKT, et al. Factors Affecting the Prognosis of Pyogenic Flexor Tenosynovitis. J Bone Joint Surg Am. 2007;89(8):1742-8.

(4) Kanavel AB. Infections of the Hand. 1st ed. Philadelphia, PA: Lea & Febiger, 1912.

(5) Draeger RW, Bynum DJ Jr. Flexor Tendon Sheath Infections of the Hand. J Am Acad Orthop Surg. 2012 Jun;20(6):373-82.

(6) Kennedy CD, Huang JI, Hanel DP. In Brief: Kanavel’s Signs and Pyogenic Flexor Tenosynovitis. Clin Orthop Relat Res. 2016;474(1):280-4.

(7) Marvel BA, Budhram GR. Bedside Ultrasound in the Diagnosis of Complex Hand Infections: A Case Series. J Emerg Med. 2015;48(1):63-8.

(8) Padrez K, Bress J, Johnson B, Nagdev A. Bedside Ultrasound Identification of Infectious Flexor Tenosynovitis in the Emergency Department. West J Emerg Med. 2015;16(2):260-2.

(9) Cohen SG, Beck SC. Point-of-Care Ultrasound in the Evaluation of Pyogenic Flexor Tenosynovitis. Pediatr Emerg Care. 2015;31(11):805-7.

(10) Schecter WP, Markison RE, Jeffrey RB, Barton RM, Laing F. Use of sonography in the early detection of suppurative flexor tenosynovitis. J Hand Surg Am. 1989;14(2 Pt 1):307-10.

(11) Jeffrey RB Jr, Laing FC, Schecter WP, Markison RE, Barton RM. Acute suppurative tenosynovitis of the hand: diagnosis with US. Radiology. 1987;162:741-2.

(12) Hmamouchi I, Bahiri R, Srifi N, Aktaou S, Abougal R, Hajjaj-Hassouni N. A comparison of ultrasound and clinical examination in the detection of flexor tenosynovitis in early arthritis. BMC Musculoskelet Disord. 2011;12:91.

(13) Alcalde M, D’Agostino MA, Bruyn GAW, Möller I, Iagnocco A, Wakefield RJ, Naredo E. A systematic literature review of US definitions, scoring systems, and validity according to the OMERACT filter for tendon lesions in RA and other inflammatory joint diseases. Rheumatology. 2012;51(7):1246-60.

(14) Giladi AM, Malay S, Chung KC. Management of acute pyogenic flexor tenosynovitis: literature review and current trends. J Hand Surg Eur Vol. 2015; 40(7):720-8.

Brown Sound: Firecracker vs Testicle

Ultrasound Case of the MontH

A 20-something year old male with PMH of anxiety, depression, and ADHD presents to the Emergency Department after an accidental firecracker injury. Patient denies LOC and respiratory distress, but has a degloving injury to left anterior thigh and a macerated laceration to left wrist. Additionally, he has first degree burns to the ventral aspect of the penile shaft, partial thickness burn and stellate laceration with associated swelling of the left hemiscrotum, and diffuse tenderness of the left testicle. Denies pain to right testicle.

A scrotal ultrasound was obtained demonstrating left-sided hematocele and testicular rupture. Video with audio discussion below.

Testicular injury ultrasound

Discussion

The above images demonstrate heterogeneous echotexture within the testis as compared to the normal testicle, which has a relatively homogenous echogenicity. There appears to be an area representing herniation of the left testicular parenchyma through a defect in the tunica albuginea with associated hematocele. There is Doppler flow present in relatively equal amounts to that of the normal testicle.

The patient was taken to the OR with urology for emergency surgical exploration. Intraoperatively, patient had 200cc of hematocele evacuated. Ultimately, patient had preservation of approximately 25% of left testicular parenchyma after resection of non-viable testicular parenchyma. General surgery was able to address his other injuries in the OR as well.

Testicular rupture is most commonly the result of blunt sports-related injuries, with 12-15% involving bicyclists/motorcyclists. (1) Ultrasound for testicular rupture has a sensitivity and specificity ranging from 56 to 95%. (2) Irregular contour of the testicle is the most significant predictor of testicular rupture. A study found that the delay of performing testicular ultrasound does not lead to negative outcomes due to delayed surgical intervention. (2)

Step-wise testicular exam. Using a high-frequency linear probe, a “buddy view” should be first obtained in transverse, showing the medial aspects of both left and right testicles in order to compare relative echogenicity and size. Just as you would when you ultrasound for testicular torsion, it is important to obtain images of the normal testicle before the abnormal one. The normal (in this case, right-sided testicle) was interrogated, paying special attention to homogeneity of the testes and circumscribed contour. Then finally, the testicle of concern was ultrasounded, first in transverse and then sagittal views.

Don’t forget your setup! Optimize your exam to minimize patient discomfort. Patient was pre-medicated for with IV pain medications. Lay one towel across the patient’s thighs and suspend the scrotum over the towel. With a second towel, cover the penile shaft so only the scrotum is exposed. Use liberal amounts of gel in order to minimize contact of the probe with the painful area.

Faculty Reviewer: Kristin Dwyer

Additional Resources

https://radiopaedia.org/articles/testicular-and-scrotal-ultrasound

References

Bauer NJG. Case report: Traumatic unilateral testicular rupture. International Journal of Surgery Case Reports. 2016;25:89-90. doi:10.1016/j.ijscr.2016.05.059.

Wang A, Stormont I, Siddiqui MM. A Review of Imaging Modalities Used in the Diagnosis and Management of Scrotal Trauma. Curr Urol Rep. 2017;28(12):98. doi: 10.1007/s11934-017-0744-1.
